TRACTION
RIB
(TR)
The most popular rib pattern for steering truck tyres & all position bus tyres
CUSTOMER BENEFITS
- Tough and long lasting
- Minimum heat build-up
- Excellent steerability
PRODUCT FEATURES
- Rib type tread
- Flat tread
TRACTION RIB (TR)
| Size | 8.25-20 |
|---|---|
| Pattern | Rib |
| Load Index | G |
| Ply Rating | 14 |
| MAX INFLATED DIMENSION | |
| Over All Diameter (mm) | 1000 |
| Over All Width (mm) | 248 |
| TUBE | |
| Tube Size | 8.25-20 |
| Valve Code | TR-77A |
| RIM | |
| Size/Code | 6.5” x 20” |
| LOAD AND INFLATION | |
| Single | |
| Max Load (KG) | 2240 |
| Dual | |
| Max Load (KG) | 2000 |
| Max Pressure (PSI) | Follow Vehicle Manufacturers Recommendations |
| FLAP | |
| Code | 508-190 |
| Size | 10.00-20 |
|---|---|
| Pattern | Rib |
| Load Index | H |
| Ply Rating | 16 |
| MAX INFLATED DIMENSION | |
| Over All Diameter (mm) | 1080 |
| Over All Width (mm) | 280 |
| TUBE | |
| Tube Size | 10.00-20 |
| Valve Code | V3.02.15 |
| RIM | |
| Size/Code | 7.5” x 20” |
| LOAD AND INFLATION | |
| Single | |
| Max Load (KG) | 3000 |
| Dual | |
| Max Load (KG) | 2650 |
| Max Pressure (PSI) | Follow Vehicle Manufacturers Recommendations |
| FLAP | |
| Code | 508-190 |
| Size | 8.25-20 | 10.00-20 |
|---|---|---|
| Load Index | G | H |
| Pattern | Rib | Rib |
| Ply Rating | 14 | 16 |
| MAX INFLATED DIMENSION | ||
| Over All Diameter (mm) | 1000 | 1080 |
| Over All Width (mm) | 248 | 280 |
| TUBE | ||
| Tube Size | 8.25-20 | 10.00-20 |
| Valve Code | TR-77A | V3.02.15 |
| RIM | ||
| Size/Code | 6.5” x 20” | 7.5” x 20” |
| LOAD AND INFLATION | ||
| Single | ||
| Max Load (KG) | 2240 | 3000 |
| Dual | ||
| Max Load (KG) | 2000 | 2650 |
| Max Pressure (PSI) | Follow Vehicle Manufacturer’s Recommendation | Follow Vehicle Manufacturer’s Recommendation |
| FLAP | ||
| Code | 508-190 | 508-190 |
| Size | Make | Type | Model | Year |
|---|---|---|---|---|
| 10.00-20 | ||||
| Hino | Bias | Trucks front axle | ||
| Hino | Bias | Buses all position | ||
| Hino | Bias | Bus ja bap | ||
| Nissan | Bias | Buses all position | ||
| Nissan | Bias | Truck front axle | ||
| Isuzu | Bias | Truck front axle | ||
| Isuzu | Bias | Buses all position | ||
| 8.25-20 | ||||
| Bedford | Bias | Truck rear axle | ||
| Bedford | Bias | Bus all postion |
